| Product Name | Rated Voltage DC (V) |
Rated Current (A) |
Breaking Capacity (A) |
Typical Cold. Resistance (mOhms) |
Typical Voltage Drop (mV) |
Typical Pre-Arcing I2t (A2Sec) |
Data Sheet |
|---|---|---|---|---|---|---|---|
12 100.15
|
32 | 15 | 50 | 3.8 | 75 | 63 |
|
|
12 100.20
|
32 | 1 | 50 | 2.9 | 70 | 82 |
|
|
12 100.25
|
32 | 25 | 50 | 1.6 | 60 | 90 |
|
|
12 100.30
|
32 | 30 | 50 | 1.3 | 60 | 100 |
|
|
12 100.12
|
32 | 12 | 50 | 5.9 | 85 | 47 |
|
|
12 100.10
|
32 | 10 | 50 | 7.0 | 90 | 32 |
|
|
12 100.8
|
32 | 8 | 50 | 8.0 | 100 | 20 |
|
12 100.7
|
32 | 7 | 50 | 11.5 | 120 | 19 |
|
|
12 100.6
|
32 | 6 | 50 | 15.5 | 140 | 14 |
|
12 100.5
|
32 | 5 | 50 | 22 | 135 | 7 |
|
12 100.4.5
|
32 | 4.5 | 50 | 28 | 150 | 4.5 |
|
12 100.4
|
72 | 4 | 50 | 33 | 160 | 3.3 |
|
12 100.3.5
|
72 | 3.5 | 50 | 37 | 175 | 2.8 |
|
12 100.3
|
72 | 3 | 50 | 49 | 185 | 2.4 |
|
12 100.2.5
|
72 | 2.5 | 50 | 79 | 230 | 1.9 |
|
12 100.2
|
72 | 2 | 50 | 133 | 310 | 1.2 |
|
12 100.1.5
|
72 | 1.5 | 50 | 230 | 367 | 0.17 |
|
|
12 100.1
|
72 | 1 | 50 | 485 | 550 | 0.2 |
|
|
12 100.0.75
|
72 | 0.75 | 50 | 775 | 680 | 0.15 |
|
|
12 100.0.5
|
72 | 0.5 | 50 | 1050 | 690 | 0.0019 |
|
|
12 100.0.375
|
72 | 0.375 | 50 | 1850 | 720 | 0.00077 |
|
|
12 100.0.25
|
72 | 0.25 | 50 | 3700 | 1350 | 0.00038 |
|
